YCM Double Column Machining Center DCV5025B

DCV5025B

YCM Double Column Machining Center DCV5025B

S&T Engineers Is The Authorised Distributors Of YCM Double Column VMC Machines In India. YCM High Precision And Reliable 3-Axis DCV Series Double Column Vmc Machines For High Productivity Application. Advanced Taiwanese CNC Machining Technology In India At Best Price

Spindle

Spindle Speed (Opt.)(rpm) - 4,500(6,000/10,000) Spindle Taper (Opt.) - BBT50

Travel

Travel(mm)(X-Y-Z(Opt.)) - 5200-2500-762(1016)

ATC

Tool Magazine Capacity (Opt.)(T) - 40(60/120)

SPECIFICATION

DCV5025B
Unit
Values

Spindle Speed (Opt.)
Rpm
4,500(6,000/10,000)
Spindle Power (Opt.)
KW
25/25/45
Spindle Taper (Opt.)
BBT50

X-Axis Travel
Mm
5,200
Y-Axis Travel
Mm
2,500
Z-Axis Travel(Opt.)
Mm
762(1,016)
Distance Between Spindle Nose & Table Top
Mm
200~962 (450~1,212 [Raised Column 250] / 200~1,216 [ Z-axis Travel 1,016] )
Distance Between Columns
Mm
2,720

Table Size
Mm
5,000 X 2,400
No. T-Slot X Size X Pitch
Mm
11 X 28 X 200
Max. Load On Table
Kg
23,000

X/Y/Z Rapid Feedrate
M/min.
12/15/15
Cutting Feedrate
Mm/min.
1~10,000

Tool Magazine Capacity (Opt.)
T
40(60/120)
Tool Weight
Kg/pc
20
Max. Tool Dimension (W/O Adjacent Tools)
Mm
ø125 X 350 (ø240 X 350  )

Machine Weight
Kg
54,000
Get Quote

Superb Body Structure

  • Turcite-B design on Z-axis strengthens rigidity and damping capacity reducing overhang and vibration problems.
  • Extra wide column base with boots design prevents the headstock from leaning forward.
  • Internal ribs structure design through FEM analysis delivers high rigidity and stability.
  • In the picture, A and B are designed by competitors and YCM respectively.

Superb Body Structure

  • Turcite-B design on Z-axis strengthens rigidity and damping capacity reducing overhang and vibration problems.
  • Extra wide column base with boots design prevents the headstock from leaning forward.
  • Internal ribs structure design through FEM analysis delivers high rigidity and stability.
  • In the picture, A and B are designed by competitors and YCM respectively.

4,500 rpm Spindle With Hi-lo Gear Transmission

  • 4,500 rpm spindle speed is standard with 2-step gear transmission.
  • The spindle incorporates roller type spindle bearings for extremely high cutting rigidity.
  • The 2-step gear transmission provides 88.87 kgf-m torque output at 241 rpm ideal for machining hard material.
