SR-400/G
SKITEK Medium Speed CNC Wire EDM SR-400/G
SKITEK Medium Speed CNC Wire EDM SR-400/G Are Finest CNC Wire EDM Machines With Excellent Precision And Reliability.
Travel
Travel - (X,Y,Z) - 300*400*250
Axes Control
Axes Control - 4 Axis AC Servo (X, Y, U, V) & Z-DC Servo
Machine Dimension
Machine Dimension - 1160 X 1650 X 1850
SPECIFICATION
SR-400/G
Unit
Values
Machine Dimension
( W X L X H ) Mm
1160 X 1650 X 1850
Machine Weight
Kg
1500
Water Tank Size
W X L X H (mm)
1100 X 700 X 670
Water Tank Capacity
L
200
Table Travel (XxYxZ)
Mm
300x400x250
Table Size (WxL)
Mm
550x680
Max Work-Piece Weight
Kg
350
Max Cutting Taper/ Angle
Mm
±6° / 80
Wire Diameter
Mm
0.16- 0.20
Job Accuracy (40 Mm Thickness SKD-11 1+2 Cut)
Mm
±0.005
Repeatability
Mm
±0.005
Max Surface Finish (40 Mm Thickness SKD-11 1+2 Cut)
Um
RA≤0.8
Positional Accuracy
Mm
±0.015 / 300
Power Capacity
KVA
3
Numerical Controller
-
G Series
Input Power Capacity
-
3PH 415V AC 50HZ
Stable Cutting Speed
Mm²/min
130
Drawing Format
-
G Code, Dxf, Dat, Dwg
Data Transfer
-
USB Unit, LAN Cable
Storage File Capacity
GB
120 GB SSD
Command Input
-
Absolute / Incremental
Interpolation:
-
Linear / Circular
Axis Control
-
4 Axis AC Servo (X, Y, U, V) & Z-DC Servo
Least Increment
Mm
0.001
Max Jog Speed
Mm/min
50
Pulse Type
-
CPU Control, Adjustable Frequency
Operation Type
-
Automatic / Manual
CNC System
-
Windows 7
Display Unit
-
LED Monitor
Language
-
English
Working Solution
-
Work Solution & Pure Water
