Makino 3-Axis CNC HMC Machine A81NX

A81NX

Makino 3-Axis CNC HMC Machine A81NX

Makino 3-Axis Horizontal Machining Center Machine Specially For High Volume Parts Production Machining With High Precision And Accuracy For Demanding Cnc Metal Cutting Jobs. Horizontal Milling Machine For High Productivity Application.

Pallet

630x630

Travel(XxYxZ)(mm)

900x900x1020

Spindle

BT50 (HSK-A100)

SPECIFICATION

A81NX

Unit

Values

B-Axis

360°

Spindle RPM

Rpm

10,000 (8,000 High Torque Opt)

Spindle Taper

Taper

CAT50 (HSK-A100 Opt)

Rapid Traverse

50,000 Mm/min (Std) 36,000 Mm/min (High Torque)

Cutting Feedrate

50,000 Mm/min (Std), 36,000 Mm/min (High Torque)50,000 Mm/min (Std), 36,000 Mm/min (High Torque)

Maximum Workpiece

1000/1300

Maximum Payload

1,200 Kg (1,500 Kg Opt)

ATC Capacity

No.s

60 (80, 136, 187, 299 Opt)

Tool To Tool

Secs

1.7 Sec (12 Kg Tool)

Chip To Chip

Secs

3.7 Sec

Maximum Tool Length (Cat)

690

Maximum Tool Length HSK

690

Maximum Tool Diameter

356

Maximum Tool Weight

30 Kg (35 Kg Opt.)

Get Quote

Spindle

Makino Spindles are best in the global competitive market.
The heart of Makino machines is the spindle, which distinguishes them through features such as lower power consumption, improved surface quality, and minimized vibrations.

Master-crafted spindles

Each spindle is dedicated to specific machines, ensuring that they are meticulously engineered to deliver optimal performance for their respective applications.

Spindle

Makino Spindles are best in the global competitive market.
The heart of Makino machines is the spindle, which distinguishes them through features such as lower power consumption, improved surface quality, and minimized vibrations.

Master-crafted spindles

Each spindle is dedicated to specific machines, ensuring that they are meticulously engineered to deliver optimal performance for their respective applications.

From Rough machining to finish

From Rough machining to finish machining of larger workpiece
The reliable machine by which the productivity was pursued
Reduce non cutting time and enhance productivity
High acceleration feed axis mechanism and reduce indexing time

Shorter time to change tool

Tool Preparation time: 5sec
ATC Shutter can synchronize the opening distance to match the tool lengths
Tool to Tool:1.7sec

High Speed ring type tool magazine

Tool storage capacity:60
An inertia adaptive control is also adopted in the ring magazine. By automatically grasping the tool total weight, the tool preparation time could be attained 5 sec as well as being increased the response

Large capacity matrix magazine

Tool storage capacity: 136

Shorter time to change tool

Tool Preparation time: 5sec
ATC Shutter can synchronize the opening distance to match the tool lengths
Tool to Tool:1.7sec

High Speed ring type tool magazine

Tool storage capacity:60
An inertia adaptive control is also adopted in the ring magazine. By automatically grasping the tool total weight, the tool preparation time could be attained 5 sec as well as being increased the response

Large capacity matrix magazine

Tool storage capacity: 136

Professional 6

Control Unit that maximises machine performance
Optimizes its machining operation according to machining condition.
Even a machine is operated at high speed and high acceleration, it enables to maintain machined surface quality and shape accuracy, which in turn increase machining efficiency.
By making proper use of the machining modes, productivity can be further improved

Chip Evacuation System

Large volumes of chips in various sizes are evacuated quickly and effectively
High productive machining centers generate large volumes of chips.
To ensure efficient and reliable chip removal, the machining envelope is composed almost entirely of the slanted panels.
Coolant from the spindle head and ceiling of the guard flush the chips directly into the center trough under the table.
Large volume base coolant in the center trough washes the chips towards the lift up chip conveyor.
Spindle head washing coolant nozzle for chip removal from spindle top

Chip Evacuation System

Large volumes of chips in various sizes are evacuated quickly and effectively
High productive machining centers generate large volumes of chips.
To ensure efficient and reliable chip removal, the machining envelope is composed almost entirely of the slanted panels.
Coolant from the spindle head and ceiling of the guard flush the chips directly into the center trough under the table.
Large volume base coolant in the center trough washes the chips towards the lift up chip conveyor.
Spindle head washing coolant nozzle for chip removal from spindle top
